Name: DH-HAC-HFW1200TLMP-IL-T-0360B
Brand: Dahua
SKU: 438
Price: 8350.00 LKR
Availability: InStock

Description

Camera

Illumination0.01 lux@F2.0 (Color, 30 IRE)



Image Sensor	2 MP CMOS	Max.


	Resolution	1920 (H) × 1080 (V)	Scanning System	Progressive	Electronic Shutter Speed	PAL: 1/25 s–1/100,000 s



NTSC: 1/30 s–1/100,000 s	Min.

		0.001 lux@F2.0 (B/W, 30 IRE)

0 lux (Illuminator on)	S/N Ratio	>65 dB	Illumination Distance	40 m (131.23 ft)	Illuminator On/Off Control	Auto;Manual	Illuminator Number	4 (Multi-core light)	Angle Adjustment	Pan: 0°–360°

Tilt: 0°–90° Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

2.8 mm; 3.6 mm

Max.

Aperture

F2.0

Field of View

2.8 mm: H: 111.3°; V: 60.8°; D: 134.2°

3.6 mm: H: 89°; V: 48.2°; D: 109.1°

Close Focus Distance

2.8 mm: 0.5 m (1.64 ft)

3.6 mm: 0.7 m (2.30 ft)

DORI Distance

( 133.20 ft)16.2 m

( 53.15 ft)8.1 m

( 26.57 ft)4.1 m

( 163.71 ft)20.0 m

( 65.62 ft)10.0 m

( 32.81 ft)5.0 m



Lens	Detect	Observe	Recognize	Identify	2.8 mm	40.6 m



( 13.45 ft)	3.6 mm	49.9 m



( 16.40 ft)	*DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area.

The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.

Video

Video Frame RateCVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps;

			AHD: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps;

CVBS: PAL: 960H; NTSC: 960H	Resolution	1080p (1920 × 1080); 960H (960 × 576/960 × 480)	Day/Night	Auto(ICR)/Color/B/W	BLC	BLC; HLC; WDR; HLC-Pro	WDR	DWDR	White Balance	Auto	Gain Control	Manual;Auto	Noise Reduction	3D NR	Illumination Mode	Smart IR&WL (CVI, TVI); WL Mode; IR Mode	Mirror	Yes	Pick-up Distance	8 m (26.25 ft)

Certification

CertificationsCE-LVD: EN 62368-1;

			CE-EMC: EN 55032; EN 55035;

Audio



Built-in Mic	Yes, up to 8 m (26.25 ft)	Camera Audio	CVI; TVI	Two-way Talk	Yes (CVI, TVI)	Speaker	Yes, up to 8 m (26.25 ft)

Port

Video OutputVideo output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)

Power



Power Supply	12 VDC (±30%) (It is recommended to use a power adapter to supply the power for one camera)	Power Consumption	Max 9.37 W (12 VDC, IR on)

Environment



Operating Temperature	–40 °C to +60 °C (–40 °F to +140 °F)	Operating Humidity



<95% (RH), non-condensing	Storage Temperature	–40 °C to +60 °C (–40 °F to +140 °F)	Storage Humidity



<95% (RH), non-condensing	Protection	IP67	Anti-corrosion Level	Basic Protection

Structure



Casing Material	Metal front cover + plastic rear barrel + metal bracket	Product Dimensions	198.4 mm × 80.2 mm × 76.2 mm (7.81″ × 3.16″ × 3.00″)


	(L × W × H)	Net Weight	0.34 kg (0.75 lb)	Gross Weight	0.49 kg (1.08 lb)	Installation	Wall mount; ceiling mount; vertical pole mount

Additional information

Weight	0.49 g
Dimensions	19.84 × 8.02 × 7.62 mm
